Utilized in various functions, leaf chains are regulated by ANSI. They could be utilized for forklift masts, as balancers between heads and counterweight in several machine tools, and for low-speed pulling and tension linkage. Leaf chains are sometimes also referred to as Balance Chains.
Features and Construction
Leaf chains are actually steel chains utilizing a simple pin construction and link plate. The chain number refers to the lacing of the links and the pitch. The chains have particular features like high tensile strength per section area, which enables the design of smaller devices. There are B- and A+ kind chains in this series and both the BL6 and AL6 Series include the same pitch as RS60. Finally, these chains cannot be driven using sprockets.
Handling and Selection
In roller chains, the link plates maintain a higher fatigue resistance because of the compressive tension of press fits, yet the leaf chain only has two outer press fit plates. On the leaf chain, the maximum permissible tension is low and the tensile strength is high. When handling leaf chains it is vital to consult the manufacturer's instruction booklet so as to guarantee the safety factor is outlined and use safety guards all the time. It is a better idea to apply extreme care and use extra safety measures in functions wherein the consequences of chain failure are severe.
Higher tensile strength is a direct correlation to the use of more plates. As the utilization of much more plates does not improve the maximum acceptable tension directly, the number of plates could be restricted. The chains require frequent lubrication because the pins link directly on the plates, producing an extremely high bearing pressure. Making use of a SAE 30 or 40 machine oil is normally suggested for nearly all applications. If the chain is cycled over one thousand times daily or if the chain speed is over 30m per minute, it will wear very rapidly, even with continuous lubrication. So, in either of these conditions utilizing RS Roller Chains will be more suitable.
The AL-type of chains must just be used under particular situations such as if wear is not a huge issue, if there are no shock loads, the number of cycles does not go over 100 every day. The BL-type will be better suited under other situations.
If a chain utilizing a lower safety factor is selected then the stress load in parts will become higher. If chains are used with corrosive elements, then they may become fatigued and break somewhat easily. Performing regular maintenance is really essential when operating under these kinds of conditions.
The outer link or inner link kind of end link on the chain would determine the shape of the clevis. Clevis connectors or likewise known as Clevis pins are constructed by manufacturers, but the user typically supplies the clevis. A wrongly constructed clevis can lessen the working life of the chain. The strands should be finished to length by the maker. Check the ANSI standard or call the manufacturer.
